6900, 69PB and 6950 Series

6900, 69PB and 6950 Series 2018-03-15T18:25:36+00:00

Compact, Versatile, Dependable

Clean heavy duty designs and premium components and a 1-1/2″ super low profile make these compact floor scales ideal for many years of Sustained Accuracy™ and dependable weighing or counting. Live side rails for oversize cargo. Wet or dry, permanent or portable, heavy materials or light – no matter what you weigh, the 6900 series industrial platform scales will outperform the competition in a wide range of applications.

  • 6900 Series with detachable ramp in (2) sizes
  • 69PB Series with wheels, folding ramp, and live column for portability
  • 6950 Series with ‘live’ integral ramps or backstop and one ramp
Download Sell Sheet

Features

  • 1-1/2″ platform height allows for compact ramp(s)
  • Capacity 1000 lbs /500 kgs (optional capacities – contact factory)
  • Rugged heavy duty design
  • (4) Single end shear beam load cells with 100% end loading and adjustable leveling feet
  • Black powder-coated finish (or sand blast SS as specified)
  • 20′ cable to digital indicator includes factory matching at no cost
  • Live side rails for bulky or oversized cargo add 4-1/2″ to width specification
  • Ideal for portable or permanent installations and where space is tight
  • (1) Ramp included; 2nd ramp is optional
  • Smooth plate surface is standard with safety plate ramp surfaces
  • Custom sizes up to 48″ wide x 60″ long – contact factory
  • 69PB MODELS include retracting wheels, ‘live’ indicator column, hinged ramp for portability (may not be moved under load)
  • 6950 MODELS include either (2) live ramps or (1) ramp with backstop

Want more info about this product?

Fill out our contact form and we’ll get back to you!

  • This field is for validation purposes and should be left unchanged.

Technical Specifications

Applications

  • Drums, kegs, or barrels – loaded with wheeled cart or bin
  • Commercial industrial LAUNDRIES
  • Shipping or receiving including weight or count
  • Food or chemical processing
  • General utility in a wide range of applications

Physical Dimensions

M69PB and SS69PB: Flat weighing surface 30″ x 30″; 1-1/2″ high platform. Package includes (1) hinged ramp 30″ w x 18″ l, retracting wheels, live indicator column and live side rails. 2nd ramp can be added at any time. No custom sizes available for this model.

M6900 and SS6900 in standard sizes: Flat weighing surface 30″ x 30″ or 36″ x 36″; 1-1/2″ high platform. Package includes (1) ramp with attachment brackets 30″ or 36″ w x 18″ l. 2nd ramp can be added at any time. Contact factory for custom sizes.

M6950 with live ramps: Flat surface 30″ x 30″ with (2) 9″ live ramps for total length of 48″. Optional configuration: 30″ x 42″ flat surface with backstop and (1) 9″ live ramp for a total length of 51″. Contact factory for custom sizes or design.

Load Cell Specifications

  • (4) Single end shear beam load cells, SS for SS models, with adjustable leveling feet
  • 100% end loading
  • Adjustable corner trim
  • Free matching and drop shipping when purchased with any Pennsylvania brand indicator or parts counting console.

Warranty

The parts and components of these Pennsylvania Scale Company products have a Limited Warranty for two years from date of retail delivery or shipment against defects in materials or workmanship, subject to the terms and conditions of our standard warranty.
